Cylinder support brackets provide a quick and easy solution for storing gas cylinders when space is at premium. Constructed from heavy gauge, powder-coated steel to ensure long service life and chemical resistance. Heavy-duty polypropylene support straps, 1.5- x 54-in (38-mm x 1372-mm) and rated at 1138-lb (516-kg), feature steel cinch buckle and hold individual cylinders securely against bracket. Welded and plated, heavy-duty size 2/0 steel chains with twist link allows links to lay flat against the cylinders, enabling a tighter fit and preventing damage to required labeling.
Helps comply with OSHA, NFP1, NFPA 55, and CGA.
Product Summary:
- Brackets accept cylinder sizes ranging from 4- to 12-in (102- to 305-mm)
- Exclusive bumper guard edging with steel reinforced vinyl protects your cylinders from damage while providing extra grip
- Includes secondary support chain for an improved level of safety on any installation
- Designed for wall mounting applications
Specifications
| Model No | 35268 |
|---|---|
| UPC | 697841210905 |
| Cylinder Capacity | 2 |
| Minimum Cylinder Diam (in) | 4 |
| Cylinder Capacity with Max Cylinder Dia | (2) 12 inch |
| Mount Type | Wall |
| Mount Holes | 4 |
| Mount Hole Size (inch) | 0.406 |
| Strap Style | Poly Cinch Strap with Steel Buckle and Chain |
| Straps Per Cylinder | 1 |
| Material Specifications | Steel |
| Complies with NFPA 1 Fire-Code | Yes |
| NFPA 55 | Yes |
| OSHA Compliance | Yes |
| CGA | Yes |
| Net Weight, lbs | 9 |
| Net Weight, kg | 4 |
| Net Dimensions (W x D x H) | 23.75 x 2.25 x 4.25 inches |
| 603 x 57 x 108 mm |
Documentation:
Gas-Cylinder-Storage-Handling-Catalog_2020 (1) (3.47 MB)
