Ideal for HPLC waste applications:
- Vapor and fire protection
- Safeguard against accidental spills
- Maximize safety and convenience
Hands-free solvent collection: Solvent flows freely from your process into the container through tubing making it suitable for either pump-fed or gravity-flow HPLC waste methods. Two disconnect fittings, one intake and one vent, eliminate back pressure in liquid flow disposal line and provide controlled handling of vapor.
Durability and safety: Translucent polyethylene container allows quick visual inspection of liquid level. Pouring spout is equipped with a stainless steel flame arrester, which reliably dissipates heat to prevent flashback ignition. Spring-loaded, sealed lid automatically vents to guard against explosion. Control odors with a coalescing/carbon filter.
Quick-Disconnect system
- Easy-on, easy-off mechanism offers detachment of the can from the process without leaks, drips or vapor release. Once disconnected, the container is automatically sealed to prevent spills.
- Valved quick-disconnect fittings automatically close when decoupled to prevent vapor or liquid release.
- Stainless-steel fittings offer PTFE O-rings on standard containers. Also available with EPDM O-ring seals on customized cans.
- Coalescing carbon filter Optional filters are for use with only round style cans.Easy-carrying handle with fixed position latch keeps spring loaded cover open for convenient pouring during disposal.
- Economically priced polypropylene barbed fittings offer EPDM O-rings.
- Translucent color lets you check liquid level at a glance.
Product Summary:
- Ideal for HPLC waste applications
- Provides hands-free solvent collection
- Durable and safe
- Features quick-disconnect system
Specifications
Model No | PP12752 |
---|---|
UPC | 697841049710 |
International Model No. | PP12752 |
Pallet Quantity | 27 |
FM Approval | Yes |
OSHA Compliance | Yes |
Complies with NFPA Code 30 | Yes |
Color | white |
Material Specifications | Polyethylene/Polypropylene Disconnects |
Dimensions, Exterior | 14.75" H x 12" Outer Dia. |
375mm H x 305mm Outer Dia. | |
Capacity | 2 gallon |
Liter Capacity | 8 |
Fill/Pour Hole inch | 3.65 |
Fill/Pour Hole mm | 93 |
Net Weight, lbs | 6.3 |
Net Weight, kg | 2.9 |
