Standard features include:
- 2-hour fire-rated construction — backed by a 15-year structural warranty
- 90-minute fire-rated door — third party tested and labeled
- Gravity air flow vents — UL Listed fire dampers with fusible links
- Secondary containment — leakproof all welded sump
- Removable, galvanized steel grate flooring
- 42-inch (1.07-m) wide door with UL Listed, keyed lockset for security
- Door closer — ensures doors close automatically
- NFPA 704 diamond decal provides "Right to Know" information
- Multiple static grounding connections
- Anchoring plates for maximum hold down protection
- Chemical and UV resistant coating, inside and out
- Forklift channels for easy relocation
- Meets EPA, NFPA 30 and NFPA 1 requirements
- FM-approved — including third party tested, fire-rated wall and roof design
Customize the locker to meet specific applications with a variety of optional features and accessories, including loading ramp, shelving, grounding kit, fire protection, heating/cooling, insulation, and lighting packages.
NOTE: Exterior dimensions include anchoring plates and door hardware.
Product Summary:
- 2-hour fire-rated construction for safe and secure storage of flammables and combustibles
- 90-minute fire rated door
- Meets EPA, NFPA 30 and NFPA 1 requirements; FM-approved
- Customizable with a variety of optional features and accessories
Specifications
Model No | 912020 |
---|---|
UPC | 697841158597 |
International Model No. | 912020 |
Color | Bone |
Material Specifications | Steel |
FM Approval | Yes |
UL Approval | Doors |
Complies with NFPA Code 30 | Yes |
Complies with NFPA 1 Fire-Code | Yes |
EPA Compliance | Yes |
Dimensions, Exterior | 77.5" H x 71" W x 42" D |
1969mm H x 1803mm W x 1676mm D | |
Dimensions, Interior | 54" H x 53.5" W x 29.5" D |
1372mm H x 1359mm W x 749mm D | |
55-Gallon Drum Capacity | 2 |
Base Capacity, lbs | 2000 |
Base Capacity, kg | 907.2 |
Number of Doors | 1 |
Door Type | Fire-rated |
Door Hinge | Left |
Door Height inch | 51 |
Door Width inch | 42 |
Door Height mm | 1295 |
Door Width mm | 1067 |
Sump Capacity - Gallons | 88 |
Sump Capacity - liters | 333 |
Sump Depth - inch | 13.5 |
Sump Depth - mm | 343 |
Storage Capacity cubic feet (Int Volume) | 49 |
Storage Capacity cubic meters (Int Volume) | 1.4 |
Net Weight, lbs | 1584.0 |
Net Weight, kg | 718.5 |
