Eagle 55 Gallon, manual close, Horizontal Drum Storage Safety Cabinet, can safely contain a 55-gallon drum of flammable liquid. The cabinet features drum supports for use with optional horizontal drum cradle, model no. 08800. Constructed of 18-gauge (1 mm) steel, the sides, top, bottom, and doors are double-walled with a 1-1/2 in (3.8 cm) air space between walls. Includes two vents, each have 2 in (5.1 cm) threaded fittings and a fire baffle and cap. Cabinets have a high gloss powder coat finish with red trilingual warning, plus grounding attachment, 3-point latch system, and 2-in (5.1 cm) raised, leakproof door sill. Cabinets are FM-Approved and meet NFPA Code 30 and OSHA requirements.
Product Summary:
- Reinforced double wall construction with 1-1/2 in (3.8 cm) air space on sides, top, bottom, back and doors
- Constructed of 18-gauge steel
- Lead-free, high-gloss, baked-on powder finish
- Continuous piano hinges
- Ground connection
- Four adjustable galvanized leveling legs
- Trilingual warning labels
- 2 in (5.1 cm) raised leakproof sill
- Internal and external welded construction
- Two 2 in (5.1 cm) internal vents with fire baffle and cap
- Flush mounted door handle with key lock
- Three-point stainless steel bullet latching system
- Self-latching doors
- Door closings: Manual Close (180° opening)
Specifications
| Model No | 1928XRED |
|---|---|
| Color | Red |
| Material Specifications | 18-Gauge Steel |
| Door Style | Manual Close |
| UPC | 048441692491 |
| Dimensions, Exterior | 30W x 48Dx 50H |
| Dimensions, Interior | 26.75" W x 44.8" D x 45.5" H (67.9 x 113.7 x 115.6 cm) |
| Number of Doors | 2 |
| Lock | Yes |
| Gallon Capacity | 55 |
| Liter Capacity | 208.2 |
| Net Weight, lbs | 323 |
| Net Weight, kgs | 146.51 |
